SF24G Rectifier Diode

Get a Price/Quote

MOQ : 1000 Units

SF24G Rectifier Diode Specification

Connector Type
Axial Leads

Mounting Type
Through Hole

Humidity %
Relative Humidity upto 95% (Non-Condensing)

Overheating Protection
NO

Shape
Cylindrical (DO-15 Package)

Operating Temperature
-65C to +150C

Efficiency
High Switching Efficiency

Surface Finish
Epoxy Coated

Insulation Material
Epoxy

IP Rating
Not Rated

Feature
Fast Recovery Diode, High Surge Capability

Product Type
Rectifier Diode

Application
General Purpose Rectification, Power Supply Circuits

Protection Level
Standard

Frequency (MHz)
Not Rated

Rated Voltage
200V (Maximum Repetitive Peak Reverse Voltage)

Output Type
DC

Color
Black Body with Silver Leads

Dimension (L*W*H)
Approx. 6.8mm x 2.7mm

Weight
0.32g (approx)

Input Voltage
200V Peak Reverse

Phase
Single

Size
DO-15

No Of Poles
2

Connection Type
Axial Lead

Material
Silicon

Average Forward Current (IF(av))
2A

Reverse Leakage Current (IR)
5A (Max) at 25C

Compliance
RoHS Compliant

Polarity
Cathode Marked by Band

Peak Forward Surge Current (IFSM)
60A (8.3ms Single Half Sine-Wave)

Forward Voltage (VF)
1.3V (Max) at 2A

Reverse Recovery Time (trr)
150 ns (Typical)

SF24G Rectifier Diode Trade Information

Minimum Order Quantity
1000 Units

Payment Terms
Cash in Advance (CID)

Supply Ability
50000 Units Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About SF24G Rectifier Diode

Experience matchless performance and heroic reliability with the SF24G Rectifier Diode, designed for advanced purchase by discerning manufacturers, distributors, and suppliers in India. Boasting a crackerjack average forward current of 2A and a peak surge capability of 60A, this latest silicon diode exemplifies high switching efficiency and fast recovery (150 ns typical). Its robust through-hole mounting, RoHS compliance, and epoxy-coated DO-15 cylindrical package guarantee durability in general purpose rectification and power supply circuits. Select the SF24G for superior general rectification-where performance meets dependability.

Applications & Usage Guidelines

For optimal results, integrate the SF24G Rectifier Diode in power supply circuits and general-purpose rectification scenarios. Direction of use involves connecting the diode with correct polarity (cathode marked by a band) via its axial leads. Ideal for protection and conversion tasks, its fast recovery and high surge capacity make it suitable for industrial and commercial assemblies. The diode's cylindrical DO-15 design ensures easy integration and dependable results across varied voltage conditions.

Export Markets & Dispatch Policies

SF24G Rectifier Diode enjoys strong demand across international markets, notably in Asia, Europe, and the Middle East. We offer prompt goods transport through established FOB Indian ports, assuring secure and timely dispatch. Our sample policy is designed to support evaluation and testing, with trial quantities available upon request. Professional handling and streamlined processing ensure every consignment maintains the highest standards of quality, ready to meet your industrial or commercial requirements efficiently.

FAQ's of SF24G Rectifier Diode:

Q: How is the SF24G Rectifier Diode typically used in electronics applications?

A: The SF24G Rectifier Diode is primarily employed for general purpose rectification and in power supply circuits to convert AC to DC, safeguarding sensitive components and ensuring stable circuit operation.

Q: What is the importance of the diode's fast recovery time and high surge capability?

A: Its fast recovery time of 150 ns and 60A surge capability allow the SF24G to handle sudden current spikes efficiently, making it particularly useful in circuits requiring quick switching and robust surge protection.

Q: Where should the SF24G Rectifier Diode be installed for proper operation?

A: Install the diode with the cathode side (indicated by the band) in alignment with your circuit's polarity requirements. The through-hole axial lead design suits both PCB and chassis mounting.

Q: What benefits do distributors and suppliers gain from selecting the SF24G?

A: Distributors and suppliers benefit from its RoHS compliance, high reliability, and proven performance, making it a dependable choice for clients in various industrial and commercial sectors.

Q: How does the sample policy facilitate trial usage of the SF24G Diode?

A: Our sample policy provides trial quantities upon request, allowing customers to evaluate the diode's performance in their specific applications before proceeding with volume purchases.
