CD4042 Integrated Circuit

Get a Price/Quote

CD4042 Integrated Circuit Specification

Humidity %
Max 95% RH (non-condensing, storage)

Shape
Rectangular (DIP/DIL-16)

Operating Temperature
-55C to +125C

Surface Finish
Matte epoxy/plastic

Power Factor
N/A (Digital IC)

Feature
Quad D Latch with common clock, true and complement outputs

IP Rating
Not Rated (general electronics)

Insulation Material
Epoxy/plastic body

Connector Type
DIP-16 pinout

Mounting Type
Through Hole (DIP)

Efficiency
High (low static power)

Product Type
CMOS Integrated Circuit

Application
Data latching, digital electronics, signal holding, memory buffers

Protection Level
ESD sensitive, standard IC static precautions

Frequency (MHz)
DC to 8 MHz (typical operation)

Rated Voltage
3V to 15V (VDD supply)

Energy Consumption
Very Low (CMOS, typically <1 W static)

Output Type
Parallel Q outputs

Color
Black (with silver pins)

Dimension (L*W*H)
Approx. 20mm x 7mm x 4mm (DIP-16)

Weight
Approx. 1g (IC only)

Size
16-pin Dual Inline (DIP16)

Input Voltage
3V - 15V

Phase
N/A (Digital IC)

Connection Type
Through Hole (DIP-16 pin)

Material
Plastic (body), metal (leads)

No Of Poles
N/A (IC - not applicable)

Logic Family
CD4000 CMOS

Pin Count
16

Latch Type
D-type Latch

Number of Channels
4 (Quad Latch)

Propagation Delay
Approx. 120ns @ 10V

Output Current
+/-3.4mA @ 15V VDD

Manufacturers
Texas Instruments, ON Semiconductor, STMicroelectronics, etc.

Input Type
TTL/CMOS compatible

RoHS Compliant
Yes

CD4042 Integrated Circuit Trade Information

Minimum Order Quantity
100 Number

Payment Terms
Cash in Advance (CID)

Supply Ability
50000 Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About CD4042 Integrated Circuit

Unlock an imposing level of digital performance with the renowned CD4042 Integrated Circuit. This splendiferous Quad D-Type Latch IC, part of the admired CD4000 CMOS logic family, is a must-have for digital electronics enthusiasts. It supports both TTL and CMOS inputs, providing flexibility for diverse applications. Offering parallel Q outputs, robust +/-3.4mA output current, and a swift 120ns propagation delay, this IC ensures efficient data latching and signal processing. Its matte black rectangular DIP-16 package promotes easy integration, while RoHS compliance underscores eco-conscious design. Enjoy a Discount-Try Now and elevate your electronic projects!

Versatile Usage & Advanced Features

The CD4042 Integrated Circuit is ideal for data latching, digital electronics, signal holding, and memory buffer applications. Its usage type encompasses industrial automation, instrumentation, and hobbyist projects, making it a highly versatile solution. Extra features include true and complement parallel outputs, compatibility with both TTL and CMOS inputs, and ultra-low static power consumption. With its ESD-sensitive protection level and operating range of -55C to +125C, it stands out as a reliable, robust choice for sophisticated digital designs.

Sample Accessibility and Global Reach

Sample CD4042 ICs are readily available for evaluation and prototyping, streamlining the process for swift exchange and implementation. With significant supply ability, distributors, manufacturers, and suppliers in India ensure seamless transportation and rapid fulfillment, supporting bulk and retail outlay. The main export markets extend across Asia, Europe, and North America, providing robust global reach. This ensures reliable and efficient access for buyers worldwide, reducing lead time and simplifying procurement logistics.

FAQ's of CD4042 Integrated Circuit:

Q: How should I handle the CD4042 IC to ensure safe usage?

A: The CD4042 IC is ESD sensitive. It is essential to follow standard static precautions, such as wearing an anti-static wrist strap and working on a grounded surface, to protect the IC from electrostatic damage during handling and installation.

Q: What are the typical applications of the CD4042 Integrated Circuit?

A: The CD4042 is used in data latching, digital electronics, memory buffers, and signal holding applications, making it suitable for both industrial automation and electronic hobbyist projects.

Q: When should I choose the CD4042 over similar quad latches?

A: Opt for the CD4042 when you require a CMOS device with very low static power consumption, TTL/CMOS compatibility, a broad supply voltage range (3V-15V), and operation in harsh environments with wide temperature variations.

Q: Where is the CD4042 IC manufactured and supplied from?

A: The CD4042 IC is manufactured by renowned brands such as Texas Instruments, ON Semiconductor, and STMicroelectronics, with distributors and suppliers located throughout India and serving global markets.

Q: What are the benefits of using a quad D-type latch with parallel Q outputs?

A: A quad D-type latch like the CD4042 allows simultaneous data storage across four channels and provides both true and complement parallel outputs, enhancing flexibility in clocked data storage and retrieval processes.
