MJE15032G Integrated Circuit

Get a Price/Quote

MJE15032G Integrated Circuit Specification

Surface Finish
Standard/Matte

Feature
High Voltage, High Current, Fast Switching

Shape
TO-220

Operating Temperature
-65C to +150C

Overheating Protection
NO

Insulation Material
Epoxy Molded

Mounting Type
Through Hole

Product Type
NPN Power Transistor

Application
Audio Amplifiers, Switching Circuits, Power Amplifiers

Protection Level
Standard

Frequency (MHz)
30 MHz

Rated Voltage
250 V

Output Type
NPN Bipolar Transistor

Color
Black

Dimension (L*W*H)
15.75 x 10.16 x 4.7 mm

Weight
2.2 g

Size
Standard TO-220

Connection Type
Through Hole

Material
Plastic, Silicon

Package Type
TO-220

Polarity
NPN

Collector-Base Voltage (Vcb)
250 V

DC Current Gain (hFE)
30-150

Lead Pitch
2.54 mm

Base Type
Through Hole

Collector Current (Ic)
8 A

Emitter-Base Voltage (Veb)
5 V

Complementary Device
MJE15033G (PNP)

Collector-Emitter Voltage (Vce)
250 V

Power Dissipation (Ptot)
50 W

MJE15032G Integrated Circuit Trade Information

Minimum Order Quantity
1000 Number

Payment Terms
Cash in Advance (CID)

Supply Ability
50000 Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About MJE15032G Integrated Circuit

The MJE15032G Integrated Circuit is a top-rated NPN bipolar transistor designed for demanding applications such as audio amplifiers, switching circuits, and power amplifiers. With an extraordinary Collector-Emitter Voltage of 250V and high collector current capacity of 8A, this unassailable device handles intense operations effortlessly. Featuring a DC current gain of 30-150, fast switching times, and a robust TO-220 package, it is crafted as a true masterpiece in its class. Order today to experience special high-voltage performance, reliability, and operational excellence in every application. Ideal for distributors, manufacturers, suppliers, and traders across India.

Competitive Advantages and Special Features of MJE15032G

Boasting a high voltage rating of 250V, the MJE15032G excels in delivering consistent performance under strenuous conditions. This NPN bipolar transistor features high current capability (8A) and a wide DC current gain, ensuring it meets various audio and power amplification needs. Its robust TO-220 package, epoxy-molded insulation, and fast switching characteristics provide exceptional stability and reliability. These competitive advantages, paired with its ease of through-hole mounting, make it a superior choice in modern circuit design.

Domestic Market, Supply Ability, and Transport Services

We offer the MJE15032G Integrated Circuit at attractive sale prices across India's main domestic market. With a strong supply ability, our network efficiently handles bulk orders from distributors, suppliers, and manufacturers. Goods are shipped quickly through reliable transport services from major FOB ports, ensuring timely delivery. Our commitment to quality and customer support makes sourcing this NPN bipolar transistor straightforward and stress-free, whether for small businesses or large-scale traders.

FAQ's of MJE15032G Integrated Circuit:

Q: How can the MJE15032G Integrated Circuit benefit power amplifier designs?

A: The MJE15032G offers high voltage and collector current ratings, providing robust amplification and reliability, which is essential for high-quality power amplifier circuits.

Q: What is the recommended process for mounting the MJE15032G?

A: This IC features a standard TO-220 package and is designed for through-hole mounting, allowing for easy integration into PCBs and quick replacement during assembly.

Q: Where is the MJE15032G IC commonly used?

A: It is widely used in audio amplifiers, power amplifiers, and switching circuits, owing to its high current, fast switching, and reliable performance.

Q: When should I select the MJE15032G for my application?

A: Choose the MJE15032G when your project demands high voltage (up to 250 V), high current (8 A), and fast operation, especially in audio, power, and switching applications.

Q: What special features make the MJE15032G stand out in the market?

A: Its extraordinary voltage capacity, robust TO-220 casing, reliable through-hole connection, and fast switching capabilities ensure it stands apart as a premium, versatile NPN transistor.
