D Sub Connector

Price 6.00 INR/ Piece

Get a Price/Quote

MOQ : 500 Pieces

D Sub Connector Specification

Insulation Material
Thermoplastic

Feature
Corrosion Resistant, Durable, Reliable Connection

Shape
Rectangular

Connector Type
Male/Female D-sub

Efficiency
N/A (Passive Connector)

Operating Temperature
-55C to +105C

Mounting Type
Panel Mount/Through Hole

Humidity %
85% RH (non-condensing)

IP Rating
IP20

Overheating Protection
Passive - Not applicable

Surface Finish
Nickel-Plated

Product Type
D Sub Connector

Application
Computer and Industrial Equipment Interfaces

Protection Level
Standard

Frequency (MHz)
50-60 MHz

Rated Voltage
250V AC/DC

Energy Consumption
N/A (Passive device)

Output Type
Signal/Data

Color
Silver with Black Insert

Dimension (L*W*H)
Approx. 30mm x 12mm x 13mm (varies by pins)

Weight
Approx. 10-15 grams

Phase
Single phase

Input Voltage
N/A (Signal/Application dependent)

Size
Standard (9 Pin, 15 Pin, 25 Pin)

Material
Metal Shell with Gold-Plated Contacts

Connection Type
Solder type/Crimp type/PCB Mount

No Of Poles
9, 15, 25 (Available variants)

Flammability Rating
UL94V-0

Dielectric Withstanding Voltage
1000V AC for 1 minute

Mating Cycles
500 cycles

Insulation Resistance
>= 5000 M at 500V DC

Shell Material
Steel, Tin-plated

Contact Resistance
20 m

Suitable Cable Size
AWG 20-26

Contact Material
Copper Alloy/Gold-plated

Standards Compliance
RoHS Compliant, IEC 60807-2

D Sub Connector Trade Information

Minimum Order Quantity
500 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
50000 Pieces Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About D Sub Connector

Discover the acclaimed D Sub Connector, a must-have solution procured by leading distributors, suppliers, and manufacturers across India. Designed for soaring reliability, this top-notch connector features a grand combination of copper alloy, gold-plated contacts, and a steel, tin-plated shell. RoHS compliant and crafted to withstand rigorous environments, it offers corrosion resistance, ultra-low contact resistance (20 m), and operates confidently at up to 1000V AC. Compatible with AWG 20-26, it supports 500 mating cycles, making it ideal for computer and industrial equipment interfaces. Available in standard 9, 15, and 25 pin variants.

Exceptional Usage Versatility & Competitive Advantages

The D Sub Connector stands out for industrial and IT applications, thanks to its varied usage types-panel mount, through-hole, solder, crimp, and PCB mount options. Its primary advantages include enduring durability, high insulation resistance, UL94V-0 flammability rating, and a corrosion-resistant metal shell. Users benefit from reliable signal integrity, easy panel integration, and a selection of pole configurations to meet diverse interface demands efficiently.

Certifications, Market Presence & Sample Arrivals

This connector proudly meets RoHS and IEC 60807-2 certifications, ensuring the highest safety and quality standards. With an extensive domestic market presence across India, industries can estimate prompt arrival, efficient packing, and quick dispatch. Samples are available to assess compatibility during procurement, guaranteeing seamless integration and satisfaction for every distributor, trader, or manufacturer in need of dependable interface solutions.

FAQ's of D Sub Connector:

Q: How can I select the right D Sub Connector variant for my application?

A: Choosing the appropriate D Sub Connector depends on your equipment's requirements and the number of poles needed (9, 15, or 25 pin). Assess cable size, connection type (solder, crimp, or PCB mount), and application (computer or industrial) to ensure optimal compatibility.

Q: What benefits does the gold-plated contact material provide?

A: Gold-plated contacts offer reduced contact resistance, exceptional conductivity, and prevent corrosion, ensuring long-lasting, reliable connections for data and signal transmission across various environments.

Q: Where is this D Sub Connector most commonly used?

A: It's widely used in computer hardware and industrial control equipment, serving as a crucial interface for signal and data exchange due to its durable construction and secure panel mounting options.

Q: What certifications does the D Sub Connector hold?

A: The connector complies with RoHS and IEC 60807-2 standards, and has a UL94V-0 flammability rating, confirming its environmental responsibility and safety for professional applications.

Q: What is the estimated delivery process for samples or bulk orders?

A: Upon request, samples or bulk orders are packed with care and dispatched promptly. Delivery timelines are estimated during procurement, with real-time tracking options available for distributors and manufacturers throughout India.

Q: How does the D Sub Connector ensure reliability during prolonged use?

A: The connector undergoes up to 500 mating cycles, maintains high insulation resistance, and uses corrosion-resistant, nickel-plated surfaces-delivering consistent performance in demanding operational conditions.
