FRC Connector

Get a Price/Quote

FRC Connector Specification

Operating Temperature
-40C to +105C

Connector Type
Flat Ribbon Cable Connector

Mounting Type
Cable Mount/PCB Mount

Feature
Polarity notch, Easy insertion, Durable locking

Efficiency
High Signal Integrity

Surface Finish
Tin Plated Contacts

Humidity %
Up to 85% RH

Shape
Rectangular

Insulation Material
PBT (Polybutylene Terephthalate)

IP Rating
Not Rated

Overheating Protection
NO

Product Type
FRC (Flat Ribbon Cable) Connector

Application
PCB connections, Data transfer, Electronic devices

Protection Level
Standard (No IP rating)

Frequency (MHz)
DC to 100 MHz

Rated Voltage
250V AC/DC

Output Type
Signal/Data

Color
Grey/Black

Dimension (L*W*H)
Based on No. of Poles, e.g. 36mm x 10mm x 7mm for 10 Way

Weight
Approx. 5 grams (varies by pin count)

Phase
Single Phase

Input Voltage
Up to 250V

Size
2.54mm Pitch

Connection Type
IDC Solderless Connection

No Of Poles
10 Poles (custom options available: 6-64 poles)

Material
Polybutylene Terephthalate (PBT), Phosphor Bronze Contacts

Wire Gauge Supported
28-26 AWG

Flame Retardant Grade
UL94V-0

Lifecycle
200 Mating Cycles

Number of Rows
2 Rows

Polarity
Polarized Design

Insulation Resistance
1000 M Min at 500V DC

Contact Resistance
20 m Max

Withstand Voltage
600V AC/Minute

FRC Connector Trade Information

Minimum Order Quantity
1000 Number

Payment Terms
Cash in Advance (CID)

Supply Ability
50000 Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About FRC Connector

Jump on the extraordinary! Introducing the FRC Connector-an unbeatable solution crafted for durability, precision, and high signal integrity. Its matchless 2-row, 10-pole construction (customizable up to 64 poles) ensures dazzling connectivity for data and signal transfer in electronic devices. With an ephemeral, solderless IDC connection and a polarized, flame-retardant PBT design, you get effortless insertion, secure locking, and 200 mating cycles. Get It Now from India's top distributor, manufacturer, supplier, and trader. Experience reliability with sleek tin-plated contacts and lasting performance across demanding commercial applications.

Unmatched Commercial Versatility and Special Features

The FRC Connector stands out for commercial applications such as PCB interconnections, electronic device assembly, and reliable data transfer. Its durable PBT body with a flame-retardant grade UL94V-0, tin-plated phosphor bronze contacts, and unique polarized design ensure safe, steady performance. With easy cable or PCB mounting and a secure IDC solderless connection, it is suited for both mass production and prototyping. Its compact size and customizable number of poles give it broad usage across automation, control, and signal transmission platforms.

Arrival, Charges, and Export Market Insights

FRC Connectors are available for immediate arrival at competitive rates, with flexible payment terms tailored to commercial requirements. A nominal charge is applicable for samples, making it easy for bulk buyers to test before ordering in large quantities. Our sample policy ensures transparency, supporting clients across various transaction sizes. Major export markets include Asia, Europe, and Africa, where the demand for high-efficiency connectors continues to grow. Get industry-leading service and global support with every shipment.

FAQ's of FRC Connector:

Q: How does the FRC Connector ensure high signal integrity?

A: The FRC Connector uses tin-plated phosphor bronze contacts and maintains low contact resistance, ensuring minimal signal loss and reliable data transfer even in environments with high-frequency applications.

Q: What applications are ideal for this connector?

A: This connector is ideal for PCB connections, electronic devices, data transfer systems, automation controls, and any scenario requiring efficient and secure ribbon cable connections.

Q: Where can the connector be mounted?

A: The FRC Connector offers versatile mounting options, suitable for both cable and PCB mounting, making it adaptable to various electronic assembly processes.

Q: What is the process for obtaining samples?

A: Clients may request samples for evaluation. A minimal sample charge applies, and samples are dispatched promptly upon acceptance of basic terms. This process helps organizations assess fit and quality before a large order.

Q: What benefit does the polarity notch provide?

A: The polarity notch ensures correct alignment and insertion, reducing the risk of mismatched connections and enhancing overall assembly reliability and speed.

Q: When is it advisable to replace the FRC Connector?

A: It is recommended to replace the connector after reaching its rated 200 mating cycles or if there is any sign of wear impacting its performance or safety.
