AT27C020 Integrated Circuit

Get a Price/Quote

AT27C020 Integrated Circuit Specification

Surface Finish
Matte molded plastic

Humidity %
Up to 90% RH (Non-condensing)

Feature
One-Time Programmable, High-Speed, Low Power

Operating Temperature
-40C to +85C

Connector Type
IC pin interface

Mounting Type
PCB, Through-Hole

Shape
Rectangular IC package

Efficiency
CMOS low power operation

Insulation Material
Plastic body with metal leads

Product Type
CMOS EPROM Integrated Circuit

Application
Microcontroller memory expansion, data storage, embedded systems

Protection Level
Standard device protection

Rated Voltage
5V (TTL compatible)

Energy Consumption
Low power CMOS technology

Output Type
Parallel

Color
Black

Dimension (L*W*H)
Standard DIP-32: approx. 40 mm x 15 mm x 5 mm

Weight
1.2 g (typical)

Size
32-pin DIP

Input Voltage
5V 10%

Material
Plastic/Dual Inline Package (DIP)

Connection Type
Through Hole

Active Current
30 mA (Max)

Data Retention
Guaranteed 10 years

Packaging
Tube/Tray

Memory Density
2 Megabit (256K x 8-bit)

Programming
One-Time Programmable (OTP)

Voltage Input Tolerance
4.5V to 5.5V

Memory Type
CMOS EPROM

RoHS Compliance
Yes

Access Time
70 ns, 90 ns, 120 ns (varies by variant)

Standby Current
100 A (Max)

UV Erasable Version
Not available (OTP only)

Pin Count
32 pins

AT27C020 Integrated Circuit Trade Information

Minimum Order Quantity
100 Number

Payment Terms
Cash in Advance (CID)

Supply Ability
50000 Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About AT27C020 Integrated Circuit

Explore first-class semiconductor performance with the AT27C020 Integrated Circuit, a decorated CMOS EPROM ideal for inestimable reliability in your embedded projects. With a robust 2 Megabit memory density (256K x 8-bit), one-time programmable (OTP) design, and rapid access times (70 ns/90 ns/120 ns), this IC is perfect for microcontroller memory expansion and secure data storage. Grab this RoHS-compliant component, presented in a sturdy 32-pin DIP plastic package, delivering low power consumption and guaranteed 10-year data retention. Order today for a premium, efficient addition to any PCB design.

AT27C020 Integrated Circuit: Versatile Memory for Broad Applications

The AT27C020 Integrated Circuit delivers robust memory expansion and data storage capabilities for microcontroller systems, embedded devices, and industrial electronics. Esteemed by engineers, developers, and manufacturers, this IC is well-suited for integration in automation, instrumentation, and control systems. Its reliable OTP design, high-speed operation, and excellent power efficiency ensure superior performance in various applications, including automotive electronics and consumer devices. This component's adaptability and impeccable credentials make it a versatile choice in both specific and general electronic use.

Efficient Sample Acquisition and Secure Packaging for AT27C020

Receive a valued sample of the AT27C020 Integrated Circuit for testing or evaluation before order completion. Each unit is thoughtfully packaged in tube/tray format, ensuring protection and safe delivery. The sample policy is designed for fair cost estimation and transparent valuation, allowing distributors, suppliers, and end-users to assess quality and compatibility. Secure packaging, coupled with reliable order processes, ensures that every batch arrives intact for optimal integration and application.

FAQ's of AT27C020 Integrated Circuit:

Q: How can I order the AT27C020 Integrated Circuit for my project?

A: The AT27C020 IC can be ordered through authorized distributors, suppliers, or manufacturers, typically found online or through semiconductor trading platforms. Ensure to specify your required access time variant and packaging preferences during the ordering process.

Q: What benefits does the AT27C020 provide in embedded system applications?

A: This IC offers inestimable reliability, fast access times, low power consumption due to CMOS technology, and secure one-time programmable memory for long-term data retention, making it highly beneficial for embedded and microcontroller-based systems.

Q: Where is the AT27C020 commonly used?

A: Common uses for the AT27C020 include microcontroller memory expansion, secure data storage in industrial electronics, automotive control modules, and a wide range of embedded system applications.

Q: What is the process for programming the AT27C020 Integrated Circuit?

A: The AT27C020 is a one-time programmable (OTP) device, meaning it can be programmed once using a dedicated EPROM programmer. Data written to the device is non-erasable, ensuring data stability for at least 10 years.

Q: When should I consider requesting a sample for evaluation?

A: Requesting a sample is recommended prior to full-scale order completion. This allows engineers and procurement specialists to estimate compatibility, test performance under real conditions, and ensure the IC meets project requirements.
