74HC4020D Integrated Circuit

Get a Price/Quote

74HC4020D Integrated Circuit Specification

Mounting Type
Surface Mount (SMD)

Feature
High-speed Si-gate CMOS, Synchronous reset

Operating Temperature
-40C to +85C

Efficiency
High (typical of CMOS logic)

Connector Type
No external connector, SMD pins

Insulation Material
Plastic Mold

Surface Finish
Matte tin-plated leads

Humidity %
Max 85% RH (non-condensing)

IP Rating
Not Rated

Shape
Rectangular (SOIC-16/SOP-16)

Product Type
14-stage Binary Ripple Counter IC

Application
Digital Electronics, Timing Applications, Frequency Division

Protection Level
ESD protected

Frequency (MHz)
Up to 25 MHz

Rated Voltage
2V to 6V DC

Energy Consumption
Low power consumption

Output Type
CMOS compatible, Parallel binary

Color
Black (body), White Markings

Dimension (L*W*H)
10.3 x 7.5 x 2.35 mm (approx, SOIC-16 package)

Weight
0.25 g (approx)

Input Voltage
2V to 6V

Size
Standard SOIC-16/SOP-16

Material
Silicon, Plastic (Encapsulation)

Connection Type
SMD (Surface Mount Device)

Number of Stages
14 stage binary counter

Quiescent Current
1 A (max at 5V)

Propagation Delay
Propagation delay: 20 ns (typical at Vcc = 5V)

Logic Type
CMOS

ESD Sensitivity
Class 1C (1000V to <2000V)

Maximum Clock Frequency
25 MHz (at Vcc = 4.5V and Ta = 25C)

Package Type
SOIC-16 (also available in TSSOP, DIP)

Reset Type
Synchronous active HIGH

RoHS Compliance
Yes

74HC4020D Integrated Circuit Trade Information

Minimum Order Quantity
100 Number

Payment Terms
Cash in Advance (CID)

Supply Ability
50000 Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About 74HC4020D Integrated Circuit

Grab the powerful 74HC4020D Integrated Circuit, featuring first-string performance for complex digital systems. With its unrivaled 14-stage binary counter and advanced high-speed Si-gate CMOS logic, this IC ensures potent, energy-efficient signal processing-up to an unprecedented 25 MHz. Designed for synchronous active HIGH resets and low quiescent current, it operates reliably from -40C to +85C. Advance purchase options are available for distributors, manufacturers, and suppliers. Shop now for innovative timing and frequency division needs across India, with full RoHS compliance and robust ESD protection.

Applications & Competitive Advantages of 74HC4020D IC

The 74HC4020D is widely used as a versatile timing device or frequency divider in digital electronics. Its primary competitive advantages stem from fast propagation, low power consumption, and high reliability-even under challenging conditions. With synchronous reset and robust ESD protection, this IC excels in automation, digital clocks, timers, and other precision applications. Its SOIC-16 form makes it suitable for compact, modern printed circuit boards, delivering superior efficiency and long-lasting performance to cutting-edge projects.

Domestic Market, Payment Terms & Supply of 74HC4020D IC

The 74HC4020D targets the expanding Indian domestic market, offering a flexible supply ability for bulk or small Purchase Orders. Sale price is tailored to suit manufacturers, distributors, and traders, ensuring value and competitive costs. Packing & Dispatch processes are streamlined for swift, safe delivery nationwide. Payment terms accommodate business needs, and strong distribution networks ensure the IC reaches diverse sectors seamlessly, supporting quick integration into various manufacturing and development pipelines.

FAQ's of 74HC4020D Integrated Circuit:

Q: How does the 74HC4020D IC benefit timing and frequency division applications?

A: The 74HC4020D's 14-stage binary counter enables accurate, high-speed timing and frequency division, making it ideal for use in clocks, timers, and digital electronics requiring precise signal processing.

Q: What are the primary usage areas for the 74HC4020D Integrated Circuit?

A: This IC finds use in digital electronics, automation systems, frequency dividers, timing circuits, and logic signal processing, owing to its high efficiency and robust CMOS technology.

Q: Where can the 74HC4020D IC be sourced in India?

A: It is readily available for advance purchase from authorized distributors, manufacturers, suppliers, and traders throughout India for seamless integration into your supply chain.

Q: What is the process for placing an order for the 74HC4020D IC?

A: Orders can be placed through a purchase order system, with flexible packaging, dispatch, and payment terms to meet specific business requirements and deadlines.

Q: When should you consider the 74HC4020D for your next project?

A: Select this IC when you need potent, reliable signal processing solutions in projects involving timing, frequency division, or complex digital logic with superior speed and efficiency.
